96W Integrated LED Driver Full-Range Dimmer & Color Temperature Controller

The Luxrite LR36141 is a compact all-in-one LED power and control solution, combining a high-efficiency Class 2 driver, full-range dimmer, and CCT (correlated color temperature) slider into a single unit. Designed for seamless integration into residential and commercial lighting systems, this micro driver delivers smooth dimming, flexible color tuning, and flicker-free 24VDC output.

• Supports 2700K-5000K
• Ultra-smooth 0–100% dimming with 4096 levels
• Fine-tuned control via touch-sensitive remote color wheel

• Linear dual-color tuning with no flicker
• 2.4GHz signal range up to 30 meters (barrier-free)
• Match up to 10 remotes per controller
• Auto-transmitting and synchronization between multiple controllers
• Works with 12–24VDC constant voltage LED tape lights
• Dual channel output: up to 120W per channel at 24V
• Power-off memory saves last light state
• Optional fade-in/fade-out on power on/off
• Power-off memory saves last light state
• Two pairing methods: button match or power cycling
• Compact, low-profile design with mounting rack included



Spec Sheet

Spec Sheet

Installation Instructions

Info

Wattage	96W
Input Voltage	120VAC, 60Hz
Output Voltage	24VDC (adjustable to 26V)
Output Current	4A
Efficiency	91% @ full load
Dimming Range	0.3% – 100%
Certifications	UL/cUL, FCC, RoHS, SELV
Environment	Dry/damp location, -40°F to 140°F
Protection	Short-circuit, overload, overheat
Warranty	5 Years
